Pre-insulated socket terminals, 0,25-1,5mm²

Code: 2A69P
Pre-insulated socket terminals, 0,25-1,5mm²
Pre-insulated socket terminals, 0,25-1,5mm²
Color gray
Material Brass
Width, mm 8.5
Length, mm 25
Material Copper
Model Sleeve
Insulation Partially isolated
Colour insulation Red
Plug dimensions Round 4 mm
Nominal cross section, mm2 0.25...1.5
Material insulation PVC
Drawings
Seria Name Eplan
Quadro - cable terminals
The System "Quadro"
RAR
27.23 MB
Certificates
Name Document
Quadro_ Exemption Letter for shrink tubes_DIN-rail, braid, frames and frames for EUI, drawing, accessories_1
PDF
1.30 MB
"Quadro"_cable lugs_EGI_1
PDF
4.29 MB
Declaration of conformity to TR TS 004/2011 for pre-insulated spade terminals
PDF
1.36 MB
Declaration of conformity to TR TS 004/2011 for pre-insulated spade terminals_1
PDF
2.65 MB
