Non Perforated Straight Element 300х50 L 2000

Material PVC
Height, mm 50
Width, mm 300
Length, mm 2000
Average filled area, sq.mm 14700
Thickness of metal sheet, mm 0,8
Colour Light grey
Width, mm 300
Model Without connector
Height, mm 50
Surface protection Sendzimir galvanized
Material thickness, mm 0.8
Side wall perforation No
Material quality Other
Length, mm 2000
Material Steel
Mounting perforation in bottom No
Useful cross section, mm2 14700
Accessories
Joint Plate   h. 50
Code: 37301
Reduction 300mm, H50
Code: LR5300
Divider  h. 50 mt2
Code: 36470
Zinc paint spray 473 ml
Code: 37039HDZ
Drawings
Seria Name STEP SAT Intergraph Autodesk Revit DWG (dynamic blocks) AVEVA
S5 Combitech - metal sheet trays
S5 Combitech - metal sheet trays
S5 Combitech - metal sheet trays
S5 Combitech - metal sheet trays
S5 Combitech - metal sheet trays
S5 Combitech - metal sheet trays
