CNT.6 NEUTRAL DISCONNECT TERMINAL

Code: ZCNT06
CNT.6 NEUTRAL DISCONNECT TERMINAL
CNT.6 NEUTRAL DISCONNECT TERMINAL
Color gray
Material of case Polyamide
Mounting method Other
Colour Blue
Nominal rated voltage, V 400
Number of clamp positions 1
Length, mm 51
Operation temperature, °C -40…80
Width/grid dimension, mm 8
Suitable for N-busbar 3x10 mm
Connectable conductor cross section solid-core, mm² 0.5…10
Connectable conductor cross section fine-strand with cable end sleeve, mm² 0.5…4
Connectable conductor cross section fine-strand without cable end sleeve, mm² 0.2…6
Connectable conductor cross section multi-wired, mm² 0.2…2.5
Rated current In, A 41
Inflammability class of insulation material acc. with UL94 V0
Material insulation body Other
Type of electric connection Screw connection
Height at lowest possible mounting height, mm 52
Accessories
CCH/2,5-4 SCREWDRIVER
CCH/2,5-4 SCREWDRIVER
Code: ZCCH02
DIN-rail, type OMEGA 3, 35х7,5mm,
DIN-rail, type OMEGA 3, 35х7,5mm,
Code: 02135
CNT6/PT END SECTION
CNT6/PT END SECTION
Code: ZCNT601
No name
No name
Code: ZCNTSU
