TLS.2/U 8 LEVEL FEED-THROUGH TERM.BL.

Code: ZTL110
TLS.2/U 8 LEVEL FEED-THROUGH TERM.BL.
TLS.2/U 8 LEVEL FEED-THROUGH TERM.BL.
Code: ZTL110
  • To ask a question
  • Characteristics
  • Accessories
  • Drawings
  • Certificates
  • Promo
  • Viewed items
Mounting method DIN rail (top hat rail) 15 mm
Colour Beige
Length, mm 85
Operating temperature, °C -40...80
Width/grid dimension, mm 6.2
Height at lowest possible mounting height, mm 52
Closing plate required Yes
Type of indication element LED
Number of levels 3
Number of clamp positions per level 1
Supply voltage for indication, V 20...30
Voltage type for indication AC/DC
Connectable conductor cross section solid-core, mm² 0.2...4
Connectable conductor cross section fine-strand with cable end sleeve, mm² 0.5...1.5
Connectable conductor cross section fine-strand without cable end sleeve, mm² 0.2...2.5
Connectable conductor cross section multi-wired, mm² 0.2...1.5
Inflammability class of insulation material according to with UL94 V0
Type of electrical connection 1 Screw connection
Type of electrical connection 2 Screw connection
Material insulation body Other
Connection position Above
Product type Terminal block
Clamp type Screw clamp
Cross-section 2,5 mm²
Width 5 mm
Q'ty of poles 4
Number of levels 3
