No name
Code:
KH9MHK
No name
Code:
KH9MHK
| Material quality | Brass |
| Material | Metal |
| Degree of protection (IP) | IP66 |
| For Ex-zone gas | 1, 2 |
| For Ex-Zone dust | 20, 21, 22 |
| Type of a cable gland for: | unarmored cable |
| Threading | M90х2 Metric |
| Diameter of cable | From 62,8 to 71 mm |
| Marking | 1Ex db IIC Gb , 1Ex e IIC Gb , 2Ex nR IIC Gc , Ex ta IIIC Da , РВ Ex db I Mb , PП Ex e I Mc |
| Temperature range | From - 60 to +200 ° C |
| Material | Nickel plated brass |
| Product type | Cable input for tubes |
