No name

Code: KAEPM3MHK-26
Code: KAEPM3MHK-26
  • To ask a question
Material quality Brass
Material Metal
Degree of protection (IP) IP66
For Ex-zone gas 1, 2
For Ex-Zone dust 20, 21, 22
Colour Light grey
Model Straight
Surface protection Nickel-plated
Type of sealing Sealing ring
Thread type Metric
Pitch thread, mm 1.5
Flat cable coupling No
Suitable for cable diameter, mm 11.8...18
Nominal thread size metric/PG 25
Type of a cable gland for: Armored and Unarmored cable in a flexible conduit COSMEC
Threading M25х1,5 Metric
Diameter of cable From 11,8 to 18 mm
Marking 1Ex db IIC Gb , 1Ex e IIC Gb , 2Ex nR IIC Gc , Ex ta IIIC Da , РВ Ex db I Mb , PП Ex e I Mc
Temperature range From - 60 to +200 ° C
Nominal diameter of the flexible conduit, mm 26 COSMEC
Material Nickel plated brass
Product type Cable input for tubes
