Explosion-proof operation head-switch. Marking "0-I". Direction of keyslot 0°.
Code: 2361.1805.622.01
Explosion-proof operation head-switch. Marking "0-I". Direction of keyslot 0°.
Code: 2361.1805.622.01
Hole diameter, mm | 30.6 |
Number of switch positions | 2 |
Number of command positions | 1 |
Diameter cap | 39 |
Type of button | Other |
Width opening, mm | 30.6 |
Height opening, mm | 30.6 |
Switching function latching | Yes |
Colour front ring | Natural colour |
Material front ring | Plastic |
Colour button | Black |
Degree of protection (IP), front side | IP66 |
Type of element | 0–I |
Marking | Ex e IIС Gb U; Ex tb IIIC Db U |
Degree of protection | 66 |
Color | Black |
Temperature range | From –60 to +60 °C |
Control element | Switch |
