No name
Code: LCSD21000126
No name
Code: LCSD21000126
| Mounting method | Surface mounted (plaster) |
| Material | Aluminium |
| Explosion-tested version | Yes |
| Impact strength | IK07 |
| Cover attachment | Screwed |
| Degree of protection (IP) | IP66 |
| For Ex-zone gas | 1, 2 |
| For Ex-Zone dust | 21, 22 |
| Number of controls | 3 pcs. |
| Element controls 1 | Light filter |
| Type 1 element | 1 pc. x L1 green 20V-250V AC/DC |
| Element controls 2 | Push-button |
| Type 2 element | 1 pc. x P1 green 1NC+1NO |
| Element controls 3 | Push-button |
| Type 3 element | 1 pc. x P1 red 1NC+1NO |
| Type of a cable gland for | Armored and Unarmored cable in a flexible conduit "Cosmec" |
| Nominal diameter of the flexible conduit, mm | DN20 mm |
| Installation side: C | 1 pc. x outer D:10,5-18 mm & inner d: mm |
| Material | Aluminium alloy |
| Ex | d, tb |
| Electrical equipment group | IIB ethylene |
