| Ex-class | IIC |
| Number of command positions | 3 |
| Suitable for emergency stop | No |
| Material housing | Plastic |
| Number of indicator lights | 1 |
| Number of push buttons | 2 |
| Number of contacts as normally closed contact | 2 |
| Number of contacts as normally open contact | 2 |
| Degree of protection (IP) | IP66 |
| For Ex-zone gas | 1, 2 |
| For Ex-Zone dust | 21, 22 |
| Element controls 1 | Light filter |
| Type 1 element | 1 pc. x L green 20V-250V AC/DC |
| Element controls 2 | Push-button |
| Type 2 element | 1 pc. x P1 black 1NC+1NO |
| Element controls 3 | Push-button |
| Type 3 element | 1 pc. x P1 red 1NC+1NO |
| Type of a cable gland for: | Armored and Unarmored cable in a flexible conduit COSMEC |
| Nominal diameter of the flexible conduit, mm | DN20 - cable diameter up to 15 mm |
| Installation side: C | 1 pc. x outer D & inner d: 5,8-12 mm |
| Material | PVC |
| Ex | d e, tb |
| Electrical equipment group | IIC hydrogen |
| Geometric dimensions | 220x120x90 mm |
| Number of controls | 3 pcs. |
