90 downward blind vertical angleBlind horizontal T-tapper 50x50

Code: 39003
90 downward blind vertical angleBlind horizontal T-tapper 50x50
90 downward blind vertical angleBlind horizontal T-tapper 50x50
Material PVC
Height, mm 50
Width, mm 50
Thickness of metal sheet, mm 0,8
Construction type T-piece horizontal
Material quality Other
Material Steel
Inner radius, mm 100
Cable tray width, mm 50
Cable tray height, mm 50
NATO-mounting holes No
Stainless steel, pickled No
Wide span model No
Suitable for circuit integrity No
Colour Light grey
Model Included connector
Surface protection Sendzimir galvanized
