| Hole diameter, mm | 22.5 |
| Number of switch positions | 1 |
| Suitable for illumination | No |
| Number of command positions | 1 |
| Unlocking method | None |
| Spring-return | Yes |
| Suitable for emergency stop | No |
| Type of button | High |
| Width opening, mm | 22.5 |
| Height opening, mm | 22.5 |
| With front ring | Yes |
| Switching function latching | Yes |
| Colour front ring | Black |
| Material front ring | Plastic |
| Construction type lens | Round |
| Colour button | Green |
| Degree of protection (IP), front side | IP65 |
| Labelled | No |
| Product type | Control buttons and light-signaling fittings |
