Internal vertical angle, CSSS 90 adapter 600x100, included with fasteners (joint plates GTO, screws, nuts), hot galvanizing method

Code: 37078KHDZ
Internal vertical angle, CSSS 90 adapter 600x100, included with fasteners (joint plates GTO, screws, nuts), hot galvanizing method
Internal vertical angle, CSSS 90 adapter 600x100, included with fasteners (joint plates GTO, screws, nuts), hot galvanizing method
Colour Light grey
Model Integrated connector
Surface protection Hot-dip galvanized and coated
Deflection (angle) 90°
Material Steel
Cable tray width, mm 600
Cable tray height, mm 100
