| Width, mm | 75 |
| Height, mm | 199 |
| Depth, mm | 167 |
| With control unit | Yes |
| Number of digital inputs | 4 |
| Number of digital outputs | 1 |
| Number of analogue inputs | 1 |
| Number of analogue outputs | 1 |
| Number of HW-interfaces RS-485 | 1 |
| Supporting protocol for Modbus | Yes |
| Degree of protection (IP) | IP20 |
| With PC connection | Yes |
| Mains voltage, V | 200...240 |
| Mains frequency | 50/60 Hz |
| Type of converter | U converter |
| Number of phases output | 3 |
| Number of phases input | 1 |
| Max. output frequency, Hz | 600 |
| Max. output at linear load at rated output voltage, kW | 1.5 |
| Max. output voltage, V | 240 |
| Nominal output current I2N, A | 7.5 |
| Output power at rated output voltage, kW | 1.5 |
