| Model | Impact |
| Surface protection | Galvanic/electrolytic zinc plated |
| Min. drill hole depth, mm | 39 |
| Material sleeve | Brass |
| Length, mm | 34 |
| Thread size (metric) | 10 |
| Drill hole diameter, mm | 12 |
| Self boring | Yes |
| App. load pull zone, kN | 8.2 |
| Fastening provision | Stud |
| Material | Pre-galvanized |
| Threading | M10 |
| Length | 34 mm |
| Type | Brass anchor |
