current transformer CTWW 20/5A, accuracy class - 0.20, power - 1VA

Code: CTWW-20-0.2S-1
current transformer CTWW 20/5A, accuracy class - 0.20, power - 1VA
current transformer CTWW 20/5A, accuracy class - 0.20, power - 1VA
Code: CTWW-20-0.2S-1
  • To ask a question
  • Characteristics
  • Accessories
  • The accompanying goods
  • Promo
  • Viewed items
Model Attachable current transformer
Accuracy class 0.2
Opening diameter, mm 30
Number of primary inputs 1
With copper rail Yes
Primary rated current, A 20
Snap mounting No
Secondary connection Cable
Secondary rated current, A 5
Over current limiting factor FS 5
With shock protection Yes
Marking CTWW-20-0.2S-1
Series YON CT
Primary winding current 20 A
Secondary winding current 0.20833333333333
Accuracy class 0.2S
