| With seal head | No |
| Core cross section, mm² | 16 |
| Number of poles | 1 |
| Rated current In, A | 80 |
| Product type | Terminal block |
| Function | Distribution |
| Clamp type | Screws |
| Width | 30,5 mm |
| Number of levels | 1 |
| Number of connection points | 7 |
| Rated cross-section input line | 16 mm2 |
| Rated cross-section 1 | 16 mm2 |
| Max. cross-section 2 | 6 mm2 |
| Stripping length input line | 12 mm |
| Stripping length entry 1 | 12 mm |
| Stripping length entry 2 | 11 mm |
| Pollution severity | 3 |
| Max.current | 80 A |
| Rated short-time withstand current | 3 кА |
| Peak withstand current | 22 кА |
| Tightening torque | 2−3 N∙m |
| Tightening torque | 2−3 N∙m |
| Tightening torque | 1.5−2 N∙m |
| Blade size feed-in | S3 |
| Blade size entry 1 | S4 |
| Material of case | PA |
| Honest SIGN system. Commodity group | Radio‑electronic products |
| Russian Classification of Products by Economic Activities (OKPD 2) | 27.33.13.120 |
| Commodity Nomenclature of Foreign Economic Activity | 8536901000 |
