Code: POD-400
No name
No name
Code: POD-400
  • To ask a question
  • Characteristics
  • Accessories
  • Drawings
  • Promo
  • Viewed items
With seal head No
Core cross section, mm² 185
Number of poles 1
Rated current In, A 400
Product type Terminal block
Function Distribution
Clamp type Screws
Width 49 mm
Number of levels 1
Number of connection points 12
Rated cross-section input line 185 mm2
Rated cross-section 1 16 mm2
Max. cross-section 2 10 mm2
Max. cross-section 3 35 mm2
Stripping length input line 25 mm
Stripping length entry 1 10 mm
Stripping length entry 2 11 mm
Stripping length entry 3 11 mm
Pollution severity 3
Max.current 400 A
Rated short-time withstand current 24,5 кА
Peak withstand current 51 кА
Tightening torque 22−25 N∙m
Tightening torque 2−3 N∙m
Tightening torque 2−3 N∙m
Tightening torque 3.5−5 N∙m
Blade size feed-in S10
Blade size entry 1 S4
Blade size entry 2 S3
Blade size entry 3 S5
Material of case PA
Honest SIGN system. Commodity group Radio‑electronic products
Russian Classification of Products by Economic Activities (OKPD 2) 27.33.13.120
Commodity Nomenclature of Foreign Economic Activity 8536901000
