| Mounting method | DIN rail (top hat rail) 35 mm |
| Colour | Grey |
| Core cross section, mm² | 35 |
| Rated voltage, V | 1000 |
| Number of poles | 8 |
| Length, mm | 77.9 |
| Operating temperature, °C | -40...105 |
| Inflammability class of insulation material according to with UL94 | V0 |
| Width/grid dimension, mm | 31.5 |
| Height at lowest possible mounting height, mm | 48 |
| Closing plate required | No |
| Type of electrical connection 1 | Screw connection |
| Type of electrical connection 2 | Screw connection |
| Number of levels | 1 |
| Number of clamp positions per level | 8 |
| Internally connected stages | No |
| Connectable conductor cross section solid-core, mm² | 2.5...35 |
| Connectable conductor cross section fine-strand with cable end sleeve, mm² | 2.5...35 |
| Connectable conductor cross section fine-strand without cable end sleeve, mm² | 2.5...35 |
| Connectable conductor cross section multi-wired, mm² | 2.5...35 |
| Material insulation body | Thermoplastic |
| With shock protection | Yes |
| Connection position | Sideways |
| Rated current In, A | 125 |
| Explosion-tested version 'Ex e' | No |
| Product type | Terminal block |
| Function | Distribution |
| Clamp type | Screws |
| Width | 31,1 mm |
| Number of levels | 1 |
| Number of connection points | 8 |
| Rated cross-section input line | 35 mm2 |
| Rated cross-section 1 | 16 mm2 |
| Max. cross-section 2 | 16 mm2 |
| Stripping length feed-in | 12 mm |
| Stripping length entry 1 | 12 mm |
| Stripping length entry 2 | 11 mm |
| Pollution severity | 3 |
| Max.current | 125 A |
| Rated short-time withstand current | 4,2 кА |
| Peak withstand current | 30 кА |
| Tightening torque | 5−8 N∙m |
| Tightening torque | 2−3 N∙m |
| Tightening torque | 2−3 N∙m |
| Blade size feed-in | 1,0 × 5 |
| Blade size entry 1 | 1,0 × 3 |
| Blade size entry 2 | 1,0 × 3 |
| Material of case | PA |
