| Width, mm | 15.7 |
| Height, mm | 100 |
| Depth, mm | 80 |
| Power consumption, VA | 10 |
| Max. electricity consumption, A | 2 |
| Built-in width, mm | 15.7 |
| Modular version | Yes |
| Operating temperature, °C | -20...55 |
| Width in number of modular spacings | 1 |
| Voltage type of supply voltage | DC |
| Power output, W | 10 |
| Output voltage stabilized | Yes |
| Type of electric connection | Clip connection |
| Rail mounting possible | Yes |
| Wall mounting possible | No |
| Degree of protection (IP) | IP20 |
| With LED indication | Yes |
| 1st secondary output voltage, V | 5...5 |
| Rated supply voltage at DC, V | 24...24 |
| Short-circuit-proof | No |
| Max. output current 1, A | 2 |
| Nominal value output voltage 1, V | 5 |
