| Width, mm | 50 |
| Height, mm | 122 |
| Depth, mm | 121 |
| Modular version | No |
| Width in number of modular spacings | 3 |
| Voltage type of supply voltage | DC |
| Output voltage stabilized | Yes |
| Type of electric connection | Screw connection |
| Rail mounting possible | Yes |
| Degree of protection (IP) | IP20 |
| 1st secondary output voltage, V | 23.35...47.35 |
| Secondary voltage adjustable | No |
| Rated supply voltage at DC, V | 22...60 |
| Short-circuit-proof | Yes |
| Max. output current 1, A | 20 |
| Nominal value output current 1, A | 20 |
| Power consumption, VA | 480 |
| Power output, W | 480 |
