| Rated permanent current Iu, A | 6300 |
| Number of poles | 3 |
| Overload release current setting, A | 2520...6300 |
| Rated voltage, V | 380...415 |
| Degree of protection (IP) | IP20 |
| Type of electrical connection of main circuit | Rail connection |
| Type of control element | Push button |
| Rated short-circuit breaking capacity lcu at 400 V, 50 Hz, kA | 135 |
| Suitable for DIN rail (top hat rail) mounting | No |
| With under voltage release | No |
| Device construction | Built-in device slide-in technique (withdrawable) |
| Type of product | Выключатель автоматический воздушный |
| Number of auxiliary contacts as normally open contact | 6 |
| Number of auxiliary contacts as normally closed contact | 6 |
| Rated current In | 6300А |
| Breaking Capacity Limit Icu | 135kA |
| Type of contactors | H |
| Q'ty of poles | 3 |
| Execution | retractable version |
| Executing the connection method | vertical |
| Type release | LSIG + RS485 |
| Motor drive | No |
| Switching coil | No |
| Shunt coil | No |
