| Rated permanent current Iu, A | 1250 |
| Number of poles | 3 |
| Overload release current setting, A | 500...1250 |
| Rated voltage, V | 380...415 |
| Degree of protection (IP) | IP20 |
| Type of electrical connection of main circuit | Rail connection |
| Type of control element | Push button |
| Rated short-circuit breaking capacity lcu at 400 V, 50 Hz, kA | 65 |
| Suitable for DIN rail (top hat rail) mounting | No |
| With under voltage release | No |
| Device construction | Built-in device fixed built-in technique |
| Type of product | Выключатель автоматический воздушный |
| Number of auxiliary contacts as normally open contact | 6 |
| Number of auxiliary contacts as normally closed contact | 6 |
| Rated current In | 1250А |
| Breaking Capacity Limit Icu | 65kA |
| Q'ty of poles | 3 |
| Execution | Fixed execution |
| Executing the connection method | Horizontal |
| Type release | LSIG + RS485 |
| Motor drive | No |
