| Width, mm | 40 |
| Height, mm | 124 |
| Depth, mm | 117 |
| Power consumption, VA | 242 |
| Modular version | Yes |
| Width in number of modular spacings | 2.2 |
| Voltage type of supply voltage | AC/DC |
| Power output, W | 240 |
| Output voltage stabilized | Yes |
| Type of electric connection | Screw connection |
| Rail mounting possible | Yes |
| Degree of protection (IP) | IP20 |
| 1st secondary output voltage, V | 22...28 |
| Rated supply voltage at AC 50 Hz, V | 100...240 |
| Rated supply voltage at DC, V | 120...374 |
| Short-circuit-proof | Yes |
| Max. output current 1, A | 10 |
| Built-in Oring diode | Yes |
| Type of product | Power supply |
| Number of phases | 1 |
