| Nominal current, A | 32 |
| Nominal voltage, V | 250 |
| Cable length, m | 5 |
| Type of current | AC 3-phase |
| Type vehicle side | GB AC |
| Type infrastructure side | Type 2 |
| Charging mode | Mode 3 |
| Working Voltage | 440 V AC |
| Rated Current: | 32А |
| Length | 5000 ± 100 mm |
| Signal Current | 2 A, 30 V |
| Insulation Resistance | 1000 MΩ (500 V DC) |
| Withstand Voltage | 2500V AC for 1 min |
| Pin Material | Copper alloy, silver-plated |
| Flame Resistance Class | Thermoplastic, flame retardant, UL94 V-0 rated |
| Mechanical Durability | No-load insertion/withdrawal > 10,000 cycles |
| External Force Impact | Drop from 1 m height and driven over by a 2-ton vehicle |
| Cable Specification | H07BZ5-F 5*6mm²+2*0.5mm² |
| Operating Temperature | -30°C to +50°C |
| IP, IK Ratings | IP55, IK08 |
| Certification | TÜV, CQC, RoHS |
