Connectable conductor cross section solid-core, mm² |
25...25 |
|
Connectable conductor cross section multi-wired, mm² |
16...16 |
|
Ambient temperature during operating, °C |
-10...45 |
|
Additional equipment possible |
Yes |
|
Rated short-circuit breaking capacity Icn EN 60898 at 400 V, kA |
4.5 |
|
Rated short-circuit breaking capacity Icn EN 60898 at 230 V, kA |
4.5 |
|
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V, kA |
4.5 |
|
Rated short-circuit breaking capacity |
4.5 |
|
Width in number of modular spacings |
3 |
|
Number of poles (total) |
3 |
