| Mounting method | Direct attachment/single positioning |
| Release class | CLASS 10 A |
| Type of electrical connection of main circuit | Screw connection |
| Max. rated operation voltage Ue, V | 690 |
| Adjustable current range, A | 380...630 |
| Reset function automatic | No |
| Reset function push-button | Yes |
| Number of auxiliary contacts as normally open contact | 1 |
| Number of auxiliary contacts as normally closed contact | 1 |
| Type of accessories | Overload relay |
| For contactors | DSC400-630 |
| Current Adjustment Range | 380 - 630 А |
