| Mounting method | Direct attachment/single positioning |
| Release class | CLASS 10 A |
| Type of electrical connection of main circuit | Screw connection |
| Max. rated operation voltage Ue, V | 690 |
| Adjustable current range, A | 132...220 |
| Reset function automatic | No |
| Reset function push-button | Yes |
| Number of auxiliary contacts as normally open contact | 1 |
| Number of auxiliary contacts as normally closed contact | 1 |
| Type of accessories | Overload relay |
| For contactors | DSC225-265 |
| Current Adjustment Range | 132 - 220 А |
