| Mounting method | Surface mounted (plaster) |
| Extension possible | No |
| Material housing | Plastic |
| Cover model | Closed |
| Width, mm | 500 |
| Height, mm | 600 |
| Depth, mm | 230 |
| RAL-number | 7035 |
| With mounting plate | No |
| Degree of protection (IP) | IP66 |
| Product type | Wall mounted enclosure |
| Series | RAM box GRP |
| Material | GRP (fiberglass), light grey, RAL7035 |
| Height | 600 mm |
| Width | 500 mm |
| Depth | 230 mm |
| Enclosure design | Plain door, symmetrical |
| Mounting plate | Optional |
| Gasket | Polyurethane |
| Degree of protection | IP66 |
| IK | IK10 |
| Temperature range | -60...+90 °С |
