LFP battery system EOS Storage 12 V/67 Ah/857 Wh, plastic case
Code:
ESS012P067E
LFP battery system EOS Storage 12 V/67 Ah/857 Wh, plastic case
Code:
ESS012P067E
| Width, mm | 230 |
| Model | Lithium-ions |
| Height, mm | 208 |
| Depth, mm | 138 |
| Weight, kg | 8 |
| Voltage type | DC |
| Voltage, V | 10...12.8 |
| Ambient temperature, °C | 0...55 |
| Suitable for indoor installation | Yes |
| Suitable for outdoor installation | No |
| Emergency power compatible | Yes |
| Usable battery capacity, kWh | 0.69 |
| Max. depth of discharge, % | 80 |
| Number of complete charge cycles | 4000 |
| Nominal battery capacity, kWh | 0.857 |
| Charge voltage | 14.6 V |
| Recommended charge current | 15 A |
| Max charge current | 67 A |
| Rated discharge current | 34 A |
| Max discharge current | 67 A |
| EOD | 10 V |
| IP | IP65 |
