RCBO YONmax, 3P+N, 10mA, 13A, B, 6kA, type A

Code: MDR63N-3N1B13-A
Code: MDR63N-3N1B13-A
  • To ask a question
Rated current, A 13
Rated voltage, V 415
Release characteristic B
Rated fault current, A 10
Leakage current type A
Width in number of modular spacings 4
Degree of protection (IP) IP20
Number of protected poles 4
Concurrently switching N-neutral Yes
Number of poles (total) 4
Disconnection characteristic Undelayed
Tripping characteristic (current curve) B
Total number of poles 4
Type release Thermal-magnetic
Rated current In (A) 13
Rated voltage Ue (V) 400
Voltage type AC
Product/component type Residual Current Operated Circuit-Breaker with Integral Overcurrent Protection
Series YON max
