RCCB YON MDL100 3P+N 30mA 63A type АC
Code: MDL100-4P2-63-AC
RCCB YON MDL100 3P+N 30mA 63A type АC
Code: MDL100-4P2-63-AC
Mounting method | DIN rail |
Rated voltage, V | 415 |
Leakage current type | AC |
Short-circuit breaking capacity (Icw), kA | 10 |
Frequency | 50 Hz |
Degree of protection (IP) | IP20 |
Ambient temperature during operating, °C | -25...40 |
Rated impulse withstand voltage Uimp, kV | 4 |
Rated current, A | 63 |
Number of poles | 4 |
Rated fault current, mA | 0.03 |
Width in number of modular spacings | 4 |
Rated fault current., mA | 30 |
