| Type of fuse insert | G-fuse 5x20 mm |
| Rated current In, A | 6.3 |
| Rated voltage, V | 500 |
| Type of indication element for defect indication | None |
| Voltage type for defect indication | AC/DC |
| Type of fuse holder | Swivelling |
| Colour | Black |
| Length, mm | 82.3 |
| Width/grid dimension, mm | 6.2 |
| Height at lowest possible mounting height, mm | 101.7 |
| Material insulation body | Thermoplastic |
| Operating temperature, °C | -40...105 |
| Inflammability class of insulation material according to with UL94 | V0 |
| Connectable conductor cross section solid-core, mm² | 0.14...4 |
| Connectable conductor cross section fine-strand with cable end sleeve, mm² | 0.14...4 |
| Connectable conductor cross section fine-strand without cable end sleeve, mm² | 0.14...4 |
| Connectable conductor cross section multi-wired, mm² | 0.14...4 |
| Type of electrical connection 1 | Screw connection |
| Type of electrical connection 2 | Screw connection |
| Number of levels | 2 |
| Connection position | Sideways |
| Mounting method | DIN rail (top hat rail) 35 mm |
| Closing plate required | No |
| Product type | Terminal block |
| Function | Fuse holder |
| Clamp type | Screws |
| Width | 8,2 mm |
| Number of levels | 2 |
| Number of connection points | 4 |
| Rated cross-section | 4 mm2 |
| Max. cross-section | 6 mm2 |
| Two wires same cross-section | 0,14−1,5 mm2 |
| Stripping length | 9 mm |
| Rated impulse withstand voltage | 8 kV |
| Pollution severity | 3 |
| Screw size | M3 |
| Tightening torque | 0,6−0,8 N∙m |
| Blade size | 0,6 × 3,5 |
| Material of case | PA |
