| Width, mm | 366 |
| Height, mm | 210 |
| Depth, mm | 442 |
| Weight, kg | 16.6 |
| With transformer | Yes |
| Display | Standard |
| Ethernet | No |
| Input voltage, V | 165...280 |
| 3-phase power supply | No |
| AC-nominal output power, W | 500 |
| Number of DC-screw connections | 4 |
| Suitable for outdoor mounting | No |
| Max. DC- input capacity, W | 700 |
| Max. input current, A | 43 |
| MPP-voltage, V | 16...48 |
| Net monitoring | Single phase |
| Degree of protection (IP) | Other |
| Built-in battery | No |
| Number MPP tracker | 1 |
| Emergency power compatible | Yes |
| With data logging | Yes |
| Number of DC-plug connections | 2 |
| Data-exchange | Yes |
| Phase | Single-phase |
| Battery voltage | 12…12.8 VDC |
| Max. voltage PV | 60 VDC |
| Bypass | Combined, output relay |
| Communication interfaces | RS232/USB/RS485 (base); SNMP/GPRS (option) |
| Power connection | Screw terminals |
