| Mounting method | Direct attachment/single positioning |
| Release class | CLASS 10 |
| Type of electrical connection of main circuit | Screw connection |
| Max. rated operation voltage Ue, V | 690 |
| Adjustable current range, A | 63...80 |
| Reset function automatic | Yes |
| Reset function push-button | Yes |
| Number of auxiliary contacts as normally open contact | 1 |
| Number of auxiliary contacts as normally closed contact | 1 |
| Type of accessories | Overload relay |
| For contactors | DSC095-DSC105 |
| Current Adjustment Range | 63 - 80 A |
