Code: DSC065-3C00D048
Code: DSC065-3C00D048
  • To ask a question
Modular version No
Rated operation power at AC-3, 400 V, kW 30
Number of main contacts as normally open contact 3
Rated operation current Ie at AC-3, 400 V, A 65
Rated operation current Ie at AC-1, 400 V, A 110
Rated control supply voltage Us at DC, V 48...48
Type of electrical connection of main circuit Cable clamp
Voltage type for actuating DC
Rated operation current Ie at AC-4, 400 V, A 54.2
Rated operation power at AC-4, 400 V, kW 22
Type of product Contactor
