Relay interface, 1CO, 6A, AgSnO₂, 230V AC/DC, RC circuit, push-interminals

Code: IRK-230UC-1CO-PT-R
Relay interface, 1CO, 6A, AgSnO₂, 230V AC/DC, RC circuit, push-interminals
Relay interface, 1CO, 6A, AgSnO₂, 230V AC/DC, RC circuit, push-interminals
Code: IRK-230UC-1CO-PT-R
  • To ask a question
  • Characteristics
  • Accessories
  • The accompanying goods
  • Promo
  • Viewed items
Nominal current, A 6
Width, mm 6.3
Height, mm 88.5
Depth, mm 72.5
With detachable clamps No
Drive, polarization Polarized
Drive, switching attitude Mono stable
With forced-guided contacts No
Type of switch contact Single contact
Complete with socket Yes
Type of electric connection Spring clamp connection
Rated control supply voltage Us at AC 50HZ, V 230...230
Rated control supply voltage Us at AC 60HZ, V 230...230
Rated control supply voltage Us at DC, V 230...230
Degree of protection (IP) IP50
With LED indication Yes
Voltage type for actuating AC/DC
Number of contacts as change-over contact 1
