No name
Code: EJBS20E110
No name
Code: EJBS20E110
| Mounting method | Surface mounted (plaster) |
| Operational temperature, °C | -60...60 |
| Material | Stainless steel |
| Explosion-tested version | Yes |
| Degree of protection (IP) | IP66 |
| For Ex-zone gas | 1, 2 |
| For Ex-Zone dust | 21, 22 |
| Impact strength | IK07 |
| Cover attachment | Screwed |
| Type of boxes | Box, cover mounting on screws |
| Material | Stainless steel AISI 304 |
| Marking | Ex e IIC Gb U / Ex tb IIIC Db U |
| Length | 150 mm |
| Weight | 1,4 kg |
| Temperature range | From -60 to + 60 °C |
| Product type | Ex box |
| Type of protection | Ex e, tb |
| Width | 150 mm |
| Height | 90 mm |
