| Nominal dimension, mm | 344 |
| Number of appliances to build in | 1 |
| Bottom plate | Yes |
| Suitable for placing of sealing | Yes |
| Built-in opening for floor column | No |
| Levelling range, mm | 20...20 |
| Duct height, mm | 90...110 |
| Suitable for floor duct countersunk (closed) | No |
| Suitable for sub-floor duct overhead closed | No |
| Built-in opening for built-in unit | Rectangular |
| Decoupling possibility cover from base unit | Yes |
| Duct width, mm | 194...344 |
| Min. height finishing layer, mm | 90 |
| Material side wall | Steel |
| Temperature of mounting, °C | - 25 С до + 60 С |
| Temperature of operation, °C | - 25 С до + 60 С |
| Climate version | UHL4 |
| Fire protection | It is not subject to obligatory confirmation of compliance of the requirements of the Federal law №123-ФЗ 22.06.2012 |
| Product type | Metal form |
| Material | Galvanized steel |
| Number of modules | 12 |
