Current transformer CT50 1000/5А, accuracy class -0.5S, power - 10ВА

Code: CT50-1000-0.5S-10
Current transformer CT50 1000/5А, accuracy class -0.5S, power - 10ВА
Current transformer CT50 1000/5А, accuracy class -0.5S, power - 10ВА
Code: CT50-1000-0.5S-10
  • To ask a question
  • Characteristics
  • Accessories
  • The accompanying goods
  • Promo
  • Viewed items
Model Single-phase current converter
Accuracy class 0.5
Width opening, mm 50
Height opening, mm 30
Opening diameter, mm 40
Number of primary inputs 1
With copper rail No
Primary rated current, A 1000
Snap mounting No
Secondary connection Cable
Secondary rated current, A 5
Over current limiting factor FS 5
With shock protection Yes
Marking CT50-1000-0.5S-10
Series YON CT
Primary winding current 1000 A
Secondary winding current 0.20833333333333
Accuracy class 0.5S
Hole width 50 mm
