Code: CT30-150-0.2-1
Current transformer CT30 150/5А, accuracy class -0.2, power - 1ВА
Current transformer CT30 150/5А, accuracy class -0.2, power - 1ВА
Code: CT30-150-0.2-1
  • To ask a question
  • Characteristics
  • Accessories
  • The accompanying goods
  • Promo
  • Viewed items
Model Single-phase current converter
Accuracy class 0.2
Width opening, mm 30
Height opening, mm 30
Opening diameter, mm 30
Number of primary inputs 1
With copper rail No
Primary rated current, A 150
Snap mounting No
Secondary connection Cable
Secondary rated current, A 5
Over current limiting factor FS 5
With shock protection Yes
Marking CT30-150-0.2-1
Series YON CT
Primary winding current 150 A
Secondary winding current 0.20833333333333
Accuracy class 0.2
Hole width 30 mm
