current transformer CT80 300/5A, accuracy class - 0.5-2.300, power - 2.5VA

Code: CT80-300-0.5-2.5
current transformer CT80 300/5A, accuracy class - 0.5-2.300, power - 2.5VA
current transformer CT80 300/5A, accuracy class - 0.5-2.300, power - 2.5VA

current transformer CT80 300/5A, accuracy class - 0.5-2.300, power - 2.5VA

Code: CT80-300-0.5-2.5
Model Single-phase current converter
Accuracy class 0.5
Calibrated Yes
Width opening, mm 80
Height opening, mm 60
Opening diameter, mm 65
Number of primary inputs 1
With copper rail No
Primary rated current, A 300
Snap mounting No
Secondary connection Cable
Secondary rated apparent power, VA 2.5
Secondary rated current, A 5
Over current limiting factor FS 5
With shock protection Yes
Marking CT80-300-0.5-2.5
Series YON CT
Primary winding current 300 A
Secondary winding current 0.20833333333333
Accuracy class 0.5
Hole width 80 mm
