Current transformer CT60 500/5А, accuracy class -0.2, power - 3.75ВА

Code: CT60-500-0.2-3.75
Current transformer CT60 500/5А, accuracy class -0.2, power - 3.75ВА
Current transformer CT60 500/5А, accuracy class -0.2, power - 3.75ВА
Code: CT60-500-0.2-3.75
  • To ask a question
  • Characteristics
  • Accessories
  • The accompanying goods
  • Promo
  • Viewed items
Model Single-phase current converter
Accuracy class 0.2
Width opening, mm 60
Height opening, mm 50
Opening diameter, mm 50
Number of primary inputs 1
With copper rail No
Primary rated current, A 500
Snap mounting No
Secondary connection Cable
Secondary rated current, A 5
Over current limiting factor FS 5
With shock protection Yes
Marking CT60-500-0.2-3.75
Series YON CT
Primary winding current 500 A
Secondary winding current 0.20833333333333
Accuracy class 0.2
Hole width 60 mm
