Current transformer CT60 400/5А, accuracy class -0.5S, power - 3.75ВА

Code: CT60-400-0.5S-3.75
Current transformer CT60 400/5А, accuracy class -0.5S, power - 3.75ВА
Current transformer CT60 400/5А, accuracy class -0.5S, power - 3.75ВА

Current transformer CT60 400/5А, accuracy class -0.5S, power - 3.75ВА

Code: CT60-400-0.5S-3.75
Model Single-phase current converter
Accuracy class 0.5
Calibrated Yes
Width opening, mm 60
Height opening, mm 50
Opening diameter, mm 50
Number of primary inputs 1
With copper rail No
Primary rated current, A 400
Snap mounting No
Secondary connection Cable
Secondary rated apparent power, VA 3.75
Secondary rated current, A 5
Over current limiting factor FS 5
With shock protection Yes
Marking CT60-400-0.5S-3.75
Series YON CT
Primary winding current 400 A
Secondary winding current 0.20833333333333
Accuracy class 0.5S
Hole width 60 mm
