current transformer CT30 400/5A, accuracy class - 0.400, power - 5VA

Code: CT30-400-0.5-5
current transformer CT30 400/5A, accuracy class - 0.400, power - 5VA
current transformer CT30 400/5A, accuracy class - 0.400, power - 5VA
Code: CT30-400-0.5-5
  • To ask a question
  • Characteristics
  • Accessories
  • The accompanying goods
  • Promo
  • Viewed items
Model Single-phase current converter
Accuracy class 0.5
Width opening, mm 30
Height opening, mm 30
Opening diameter, mm 30
Number of primary inputs 1
With copper rail No
Primary rated current, A 400
Snap mounting No
Secondary connection Cable
Secondary rated current, A 5
Over current limiting factor FS 5
With shock protection Yes
Marking CT30-400-0.5-5
Series YON CT
Primary winding current 400 A
Secondary winding current 0.20833333333333
Accuracy class 0.5
Hole width 30 mm
