CD 90 external vertical angle 80x80, 1,2 mm,HDZ, included with fasteners (joint plates GTO, screws, nuts)
Code:
SON808KHDZ
Code:
SON808KHDZ
| Model | Included connector |
| Material thickness, mm | 1.2 |
| Deflection (angle) | 90° |
| Material quality | Steel |
| Material | Steel |
| Cable tray width, mm | 80 |
| Cable tray height, mm | 80 |
| Surface protection | Hot-dip galvanized |
| Suitable for circuit integrity | Yes |
| Change of direction | Vertically declining |
| With cover | No |
| Bend model | Smooth bend |
| Product type | System accessories |
| Type of accessories | 90º vertical external bend |
| Height | 80 mm |
| Thickness | 1.2 mm |
| Material | Hot-dip galvanized |
| Width | 80 mm |
