Backplane for sections of cabinets CAE / CQE, 600mm, 5pcs.

Code: R5FCP60
Backplane for sections of cabinets CAE / CQE, 600mm, 5pcs.
Backplane for sections of cabinets CAE / CQE, 600mm, 5pcs.
Colour Grey
Width, mm 600
Height, mm 27
With cable entry No
Suitable for enclosure building width, mm 600
Suitable for enclosure building depth, mm 24
Material Steel
Number of height units 1
With lock No
Type of surface With powder coating
Width, mm 600
Thickness, mm 2
