Tube PA6 flexible corrugatted without pull, DN12mm, HF, RoHS, HB, Din 12,2 mm, Dex 15,8 mm , color-black

Code: PA601216HB
Tube PA6 flexible corrugatted without pull, DN12mm,  HF, RoHS, HB, Din 12,2 mm, Dex 15,8 mm , color-black
  • To ask a question
Colour Black
Outer diameter, mm 15,8
Oil resistant Yes
UV resistant Yes
Halogen free Yes
Inner diameter, mm 12,2
Compressive strength, N 200
Operational temperature, °C -25...105
Bending radius, static, mm 30
Flame accelerating No
Material Polyamide 6
Tensile strength, N 300
Nominal diameter, mm 12
Nominal size in inch 1/2 inch
Degree of protection (IP) IP66
Bending strength Flexible
Lengthwise slotted No
Closable (two-part) No
Sheathing material Not sheathed
High conducting inner coating No
With draw wire No
Length 50000 mm
Diameter (nominal) 12 mm
Color Black
Material PVC
-5°С ... +60°С -25°С ... +105°С
Ingress Protection rating, IP IP66
от -25°С до +60°С from -25°С to +105°С
Shock resistance, J >1
Cord for wires No
Fire protection HB
ТУ 2248-012-47022248-2009 Technical specifications 2247-024-47022248-2009
3 года 3 years
15 лет 15 years
