| Colour | Grey |
| Width, mm | 426 |
| Height, mm | 470 |
| Depth, mm | 139 |
| RAL-number | 7035 |
| With mounting plate | Yes |
| Number of doors | 1 |
| EMC-version | Yes |
| With glazed door | Yes |
| Material | Plastic |
| Impact strength | IK09 |
| Degree of protection (IP) | IP65 |
| Suitable for metrical mounting | Yes |
| Mounting plate depth-adjustable | Yes |
| Tackable | Yes |
| With ventilation door | Yes |
| Floor installation possible | No |
| Color | gray |
| Material | PVC |
| Height | 312 mm |
| Width | 657 mm |
| Depth | 148 mm |
| Degree of protection | IP65 |
| Shock resistance, J | IK10 |
Accessories
Drawings
| Seria | Name | DWG | STEP |
|---|---|---|---|
|
Plastic modular enclosures - "RAMbase"
|
|
||
|
Plastic modular enclosures - "RAMbase"
|
|
