Type II+III SPD, 2P, L-N-PE, 20kА, remote control

Code: NX3011
Type II+III SPD, 2P, L-N-PE, 20kА, remote control
  • To ask a question
Mounting method DIN rail (top hat rail) 35 mm
Construction size 4 modular spacing
Voltage protection level, kV 1.2
Nominal discharge surge current (8/20), kA 10
Nominal voltage AC, V 230
With remote signalling contact Yes
Max. continuous voltage AC, V 275
Signalling at the device Optic
Integrated backup fuse No
Max. conductor cross section solid (solid, stranded), mm² 35
Max. conductor cross section flexible (fine-strand), mm² 25
Degree of protection (IP) IP20
Max. discharge surge current (8/20), kA 20
System configuration TN-C-S No
System configuration other No
System configuration TT Yes
System configuration TN-S Yes
System configuration TN-C No
System configuration TN No
System configuration IT No
System configuration DC No
Short-circuit breaking capacity (Isccr), kA 25
