Equipotential bonding box, 10 clamps, 6 inputs D25 mm, 120х80х50 mm, IP55
Code: NE3110
Equipotential bonding box, 10 clamps, 6 inputs D25 mm, 120х80х50 mm, IP55
Code: NE3110
| Colour | Grey |
| Width, mm | 80 |
| Depth, mm | 62 |
| Length, mm | 120 |
| Material | Plastic |
| Number of inlets | 6 |
| Cover attachment | Screwed |
| Degree of protection (IP) | IP55 |
| Shape | Rectangular |
| Type of housing feed-through | Seal membrane |
| Equipped with | Potential equalization |
| Operational temperature, °C | -25...60 |
| Surface protection | Untreated |
| Product type | Equipotential bonding |
| Number of bus connections | 10 |
| Cross section of the connecting conductors | 0,75-16 mm² |
| Application area | Equipotential bonding box |
